Modul Kamera Sony

SINCERE FIRST SF-AIMX179SY-AF-D66-ZIF camera module is in mass production with the sable supply in the current market. The image sensor is 8MP IMX179QQH5-C from SONY, which is a diagonal 5.7 mm (Type 1/3.2) CMOS active pixel type image sensor with a square pixel array and 8.08M effective pixels, IMX179 image sensor is with characteristic of the High sensitivity, low dark current, and no smear and Variable-speed shutter function, the max frame rate is 30 frame/s in and the pixel rate is >260 MHz (>30 bingkai/s pada mod Semua-piksel).
Hantar pertanyaan
pengenalan produk

Guangzhou Sincere Information Technology Ltd. ialah salah satu pengeluar dan pembekal modul kamera sony paling profesional di China. Selamat datang ke produk diskaun borong untuk dijual di sini dari kilang kami. Pesanan tersuai dialu-alukan.



REKA BENTUK TERSUAI ODM/OEM DIALU-ALUKAN!

Jaminan Kualiti Terbaik

1 tahunPengganti!

10 tahunjaminan!

Kami hanya menyediakan item baru yang asli,100%pastikan kualiti terbaik!

Semua produk telah diperiksa dan dibungkus dalam keadaan baik sebelum dihantar!


modul kamera sony: SF-AIMX179SY-AF-D66-ZIF


SINCERE FIRST SF-AIMX179SY-AF-D66-ZIF camera module is in mass production with the sable supply in the current market. The image sensor is 8MP IMX179QQH5-C from SONY, which is a diagonal 5.7 mm (Type 1/3.2) CMOS active pixel type image sensor with a square pixel array and 8.08M effective pixels, IMX179 image sensor is with characteristic of the High sensitivity, low dark current, and no smear and Variable-speed shutter function, the max frame rate is 30 frame/s in and the pixel rate is >260 MHz (>30 bingkai/s pada mod Semua-piksel). Modul kamera SONY sensor imej IMX179 CMOS 8MP ini adalah dengan jumlah piksel 3288 (H) × 2512 (V). Sudut kanta untuk modul kamera siap sedia ini ialah DFOV 66 darjah, julat pemfokusan ialah 10cm hingga infiniti, nombor F ialah 2.4, herotan TV rendah<1% and the focusing length is around 4.39mm. The head size of this IMX179 SONY camera module is around 8.5*8.5mm, when the module is far focus, the height is 5.8mm, when the module is near focus, the height is 6.0mm. The total length of the camera module is around 16.85mm, the FPC length is around 3.95mm, which is relatively short. The ouput image format of ready made SONY camera module is RGB format, the mating connector model is 0541323062 from Molex, 30pinout, the VMC part number is MA8F18293. SINCERE FIRST can support OEM service on logo, size, pinout etc. Are you interested in? SINCERE FIRST can share datasheet with you.


2021.08.06 SF-AIMX179SY_
